Eddy current sensor

  • MLW-33 series eddy current displacement sensor
  • MLW-33 series eddy current displacement sensor
MLW-33 series eddy current displacement sensorMLW-33 series eddy current displacement sensor

MLW-33 series eddy current displacement sensor

  • Product description: MLW-33 series eddy current displacement sensor with long-term reliability, non-contact measurement, anti-interference ability, from oil and other media, the application of a wide range of simple struc
  • INQUIRY


A:□□□□ 探頭代號選擇:

33

代號

名稱

量程

安裝

螺紋規格

備     注

0101

Ф8英制探頭

2mm

標準

3/8-24

兼容BN21504、330101,PHILIPS6423/10

0102

Ф8英制鎧裝探頭

2mm

標準

3/8-24

兼容BN21505、330102,PHILIPS6423/11

0103

Ф8探頭

2mm

標準

M10×1

兼容BN22811、330103,PHILIPS6423/00

0104

Ф8鎧裝探頭

2mm

標準

M10×1

兼容BN22810、330104,PHILIPS6423/01

0105

Ф8英制反裝探頭

2mm

反裝

3/8-24

兼容BN21508、330105

0106

Ф8反裝探頭

2mm

反裝

M10×1

兼容BN330106

0107

Ф8特殊定制探頭

2mm

定制

定制

☆需提供詳細探頭尺寸規格

0108

Ф8特殊定制鎧裝探頭

2mm

定制

定制

☆需提供詳細探頭尺寸規格

0201

Ф11英制探頭

4mm

標準

1/2-20

兼容BN19048

0202

Ф11英制鎧裝探頭

4mm

標準

1/2-20

兼容BN24798

0203

Ф11探頭

4mm

標準

M14×1.5

兼容BN26179

0204

Ф11鎧裝探頭

4mm

標準

M14×1.5

兼容BN26180

0205

Ф11英制反裝探頭

4mm

反裝

3/8-24

兼容BN29766

0206

Ф11英制探頭

4mm

標準

5/8-18

兼容BN81723 Ф14探頭

0207

Ф11英制鎧裝探頭

4mm

標準

5/8-18

兼容BN83936 Ф14探頭

0208

Ф11探頭

4mm

標準

M16×1.5

兼容BN81724 Ф14探頭

0209

Ф11探頭

4mm

標準

M18×1.5

兼容PHILIPS6424/00

0210

Ф11鎧裝探頭

4mm

標準

M18×1.5

兼容PHILIPS6424/01

0211

Ф11特殊定制探頭

4mm

定制

定制

☆需提供詳細探頭尺寸規格

0212

Ф11特殊定制鎧裝探頭

4mm

定制

定制

☆需提供詳細探頭尺寸規格

0303

Ф25探頭

12.5mm

標準

M30×2

兼容BN27891

0304

Ф25鎧裝探頭

12.5mm

標準

M30×2

兼容BN27891

0311

Ф25特殊定制探頭

12.5mm

定制

定制

☆需提供詳細探頭尺寸規格

0312

Ф25特殊定制鎧裝探頭

12.5mm

定制

定制

☆需提供詳細探頭尺寸規格

0321

Ф25探頭

12.5mm

電纜后出

M30×2

一體化

0322

Ф25鎧裝探頭

12.5mm

電纜后出

M30×2

一體化

0401

Ф5探頭

2 mm

標準

M8×1

0402

Ф5探頭

2 mm

標準

3/8-24

0403

Ф5反裝探頭

2 mm

反裝

M8×1

0404

Ф5反裝探頭

2 mm

反裝

3/8-24

0405

Ф5探頭

2 mm

標準

1/4-28

0406

Ф5探頭

2 mm

標準

M10×1.5

0407

Ф5探頭

2 mm

定制

0503

Ф16探頭

8 mm

標準

M22×1.5

0504

Ф16鎧裝探頭

8 mm

標準

M22×1.5


B: □□□ Unthreaded length selection:


Metric thread probe with British thread probe

Minimum thread length 2mm 0 0 2 Minimum thread length 0.1 inch 0 1
Maximum thread length 250mm 2 5 0 Maximum thread length 9.8 inch 9 8
Increase the increment 1.0mm 0 0 1 Increase the increment 0.1 inch 0 1

C: □□ Shell length selection:

Housing Dimensions in Metric Dimensions Housing Dimensions in Imperial Dimensions

Minimum housing length 20mm 0 2 Minimum housing length 0.8 inch 0 8
Maximum housing length 250mm 2 5 Maximum housing length 9.8 inch 9 8
Increase the increment 10mm 0 1 Increase the increment 0.4inch 0 4

D: □□ Cable length selection:
0.5m 0 5 4.0m 4 0
1.0m 1 0 5.0m 5 0
2.0m 2 0 9.0m 9 0

E: □□ Connector Selection:

No high frequency plug 0 0
Provide high frequency plug 0 2

■ probe selection points
▲ Select the probe, it is recommended to select the range greater than 50% of the scope of the probe to move the probe
▲ If the measured surface area can not meet the minimum specimen size requirements, you can choose to expand the linear range of small probe
▲ If the probe cable without pipeline protection, it is recommended to choose armored probe, so that the cable is not easily damaged
▲ Without special installation restrictions, usually choose the type of standard probe
▲ Unthreaded probe is to facilitate the installation: the use of screw installation, the appropriate length of non-threaded screw can be screwed into the length of the need to reduce
▲ probe shell length depends on the installation location and the measured surface distance, unless otherwise special, it is recommended to choose 40mm or 50mm long
▲ When installing with screw hole, the probe cable should be 0.5m or 1.0m long. Optionally extend the cable, which will not easily break the cable when installing the rotary probe.
▲ install the probe inside the machine, the best overall length of the probe cable should ensure that the cable connector can be outside the machine, to prevent the internal oil pollution connector
▲ special specifications of the probe, please provide detailed size data or processing drawings
